C9115AXE-I Overview
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, I Domain C9115AXE-I
Overview
C9115AXE-I Overview
Cisco 9115, 2500 Mbit/s, IEEE 802.11ac, Multi User MIMO, Grey, Status, 203 mm
Cisco® Catalyst® 9115 Series Wi-Fi 6 Access Points are the next generation of enterprise access points. They are resilient, secure, and intelligent. C9115AXE-I is the Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, I Domain.
Product Details
Cisco AP 9115 series provides these features:
- 802.11ax (Wi-Fi 6)
- Uplink/downlink OFDMA
- MU‑MIMO technology
- BSS coloring
- Target wake time
- Cisco Mobility Express
- Multigigabit Ethernet support
- Bluetooth 5.0
- Apple Features
Supported Platforms
Supported wireless LAN controllers and Software | Recommended Model |
Cisco 3500 Series Wireless Controllers | |
Cisco 5520 Series Wireless Controllers | |
Cisco 8540 Series Wireless Controllers | |
Cisco 9800 series Wireless Controllers | |
Cisco Virtual Wireless Controller | / |
Cisco Unified Wireless Network Software Release 8.9 or later | / |
Cisco IOS ® XE Software Release 16.11 or later | / |
Compare to Similar Items
SKU | Description |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, A Domain | |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, B Domain | |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, D Domain | |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, E Domain | |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, I Domain | |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, K Domain | |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, Q Domain | |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, S Domain | |
Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, Z Domain |
4x4 downlink MU-MIMO, 802.11ac, 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45), USB 2.0, regulatory domain I
- Wi-Fi 6 certifiable
- Three radios: 2.4 GHz (4x4), 5 GHz (4x4), and BLE
- OFDMA and MU-MIMO
- Multigigabit support
- Internal or external antenna
- Available with optional embedded wireless controller
- 2.4 GHz
- 5 GHz
- IEEE 802.11ac
- Power over Ethernet (PoE)
Summary Description
Cisco 9115, 2500 Mbit/s, IEEE 802.11ac, Multi User MIMO, Grey, Status, 203 mm
Need help with C9115AXE-I?
Get pricing, availability, lead time, and compatible options from our team. Chat with us live or email support@buyrouterswitch.com
Specification
C9115AXE-I Specification
C9115AXE-I Specification | |
Description | Cisco Catalyst 9115AX Access Point, External antenna; Wi-Fi 6; 4x4:4 MIMO, I Domain |
Software | ● Cisco Unified Wireless Network Software Release 8.9 or later ● Cisco IOS ® XE Software Release 16.11 or later |
Supported wireless LAN controllers | ● Cisco Catalyst 9800 Series Wireless Controllers ● Cisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller |
802.11n version 2.0 (and related) capabilities | ● 4x4 MIMO with four spatial streams ● Maximal Ratio Combining (MRC) ● 802.11n and 802.11a/g beamforming ● 20- and 40-MHz channels ● PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 Dynamic Frequency Selection (DFS) ● Cyclic Shift Diversity (CSD) support |
802.11ac | ● 4x4 downlink MU-MIMO with four spatial streams ● MRC ● 802.11ac beamforming ● 20-, 40-, 80-, and 160-MHz channels ● PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 DFS ● CSD support |
802.11ax | ● 4x4 downlink MU-MIMO with four spatial streams ● Uplink/downlink OFDMA ● TWT ● BSS coloring ● MRC ● 802.11ax beamforming ● 20-, 40-, 80-, and 160-MHz channels ● PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 DFS ● CSD support |
Integrated antenna | ● 2.4 GHz, peak gain 3 dBi, internal antenna, omnidirectional in azimuth ● 5 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth |
External antenna (sold separately) | ● Cisco Catalyst 9115AXE Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz) ● Cisco offers the industry's broadest selection of antennas, delivering optimal coverage for a variety of deployment scenarios |
Interfaces | ● 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45) – IEEE 802.3bz ● Management console port (RJ-45) ● USB 2.0 (enabled via future software) |
Indicators | ● Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors |
Dimensions (W x L x H) | ● Access point (without mounting brackets): C9115I: 8.0 x 8.0 x 1.5 in. (20.3 x 20.3 x 3.8 cm), C9115E: 8.0 x 8.0 x 1.7 in. (20.3 x 20.3 x 4.3 cm) |
Input power requirements | ● 802.3at Power over Ethernet Plus (PoE+), 802.3bt Cisco Universal PoE (Cisco UPOE+, Cisco UPOE ®) ● Cisco power injector, AIR-PWRINJ6= ● 802.3af PoE ● Cisco power injector, AIR-PWRINJ5= (Note: This injector supports only 802.3af) Note: When 802.3af PoE is the source of power, both 2.4-GHz and 5-GHz radios will be reduced to 2x2 and Ethernet downgraded to 1 Gigabit Ethernet. In addition, the USB port will be off. |
Environmental | Cisco Catalyst 9115AXI ● Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C) ● Nonoperating (storage) altitude test: 25˚C, 15,000 ft. ● Operating temperature: 32° to 122°F (0° to 50°C) ● Operating humidity: 10% to 90% (noncondensing) ● Operating altitude test: 40˚C, 9843 ft. Note: When the ambient operating temperature exceeds 40°C, the access point will shift from 4x4 to 2x2 on both the 2.4-GHz and 5-GHz radios, uplink Ethernet will downgrade to 1 Gigabit Ethernet, and the USB interface will be disabled. Cisco Catalyst 9115AXE ● Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C) ● Nonoperating (storage) altitude test: 25˚C, 15,000 ft. ● Operating temperature: -4° to 122°F (-20° to 50°C) ● Operating humidity: 10% to 90% (noncondensing) ● Operating altitude test: 40˚C, 9843 ft. |
System memory | ● 2048 MB DRAM ● 1024 MB flash |
Available transmit power settings | 2.4 GHz ● 23 dBm (200 mW) ● 20 dBm (100 mW) ● 17 dBm (50 mW) ● 14 dBm (25 mW) ● 11 dBm (12.5 mW) ● 8 dBm (6.25 mW) ● 5 dBm (3.13 mW) ● 2 dBm (1.56 mW) ● -1dBm (0.79mW) ● -4dBm (0.39mW) 5 GHz ● 23 dBm (200 mW) ● 20 dBm (100 mW) ● 17 dBm (50 mW) ● 14 dBm (25 mW) ● 11 dBm (12.5 mW) ● 8 dBm (6.25 mW) ● 5 dBm (3.13 mW) ● 2 dBm (1.56 mW) ● -1dBm (0.79mW) ● -4dBm (0.39mW) |
Frequency band and 20-MHz operating channels | I (I regulatory domain): ● 2.412 to 2.472 GHz; 13 channels |
Frequently Asked Questions
What are the primary performance benefits of the Cisco C9115AXE-I Wi-Fi 6 technology? +
The C9115AXE-I leverages Wi-Fi 6 (802.11ax) standards to deliver increased throughput and higher efficiency in dense wireless environments. By utilizing 4x4:4 MU-MIMO, this access point effectively manages multiple client streams simultaneously, significantly reducing latency and improving overall network capacity compared to legacy 802.11ac hardware. This makes it an ideal upgrade for high-traffic enterprise office spaces.
Does the C9115AXE-I support external antennas for flexible deployment? +
Yes, the C9115AXE-I model is specifically engineered with external antenna connectors. This design allows IT administrators to attach specialized antennas to optimize coverage patterns in challenging environments, such as high ceilings, narrow aisles, or areas requiring directional signal propagation. It offers greater architectural flexibility than internal-antenna models when tailoring wireless coverage to specific physical layouts.
What does the 'I' Domain designation signify for the C9115AXE-I? +
The 'I' in the C9115AXE-I model number denotes the regulatory domain for which the access point is configured. It indicates that the device is programmed to comply with the radio frequency regulations and spectrum allocations specific to its designated region. It is essential to verify that your local regulatory requirements align with the 'I' domain specifications before installation.
How does the 4x4:4 MIMO configuration improve wireless reliability? +
The 4x4:4 MIMO configuration provides four spatial streams for both transmit and receive functions. This multi-antenna approach enhances signal robustness and reliability, especially in environments prone to multipath interference. By utilizing these spatial streams, the access point can maintain higher data rates and stable connections for a larger number of devices, ensuring consistent performance for mission-critical enterprise applications.
Is the C9115AXE-I compatible with existing Cisco Catalyst 9800 series controllers? +
This access point is fully compatible with the Cisco Catalyst 9800 series wireless controllers. It is designed for seamless integration into intent-based networking architectures, allowing for unified management, advanced security policies, and simplified software updates. This compatibility ensures that your wireless infrastructure remains scalable and easy to manage as your enterprise network requirements grow and evolve.
What is the recommended deployment scenario for the Cisco Catalyst 9115AXE-I? +
The C9115AXE-I is best suited for indoor enterprise deployments where versatility in antenna placement is required. It performs exceptionally well in environments like warehouses, retail storefronts, or lecture halls where mounting flexibility is necessary to achieve optimal signal penetration. Its Wi-Fi 6 capabilities make it a reliable choice for organizations expecting high device density and heavy bandwidth utilization.
Does the C9115AXE-I require specific licensing for advanced management features? +
Cisco Catalyst 9100 series access points operate within the Cisco DNA architecture, typically requiring DNA software subscriptions to unlock advanced features like Cisco DNA Center management, SD-Access, and encrypted traffic analytics. These licenses allow for automated provisioning and deep network visibility, which are essential for maintaining large-scale, high-performance wireless infrastructures effectively.
Can I use the C9115AXE-I in high-density environments without sacrificing performance? +
Absolutely. The C9115AXE-I is engineered to handle high-density environments by utilizing OFDMA and BSS coloring, which are core features of the Wi-Fi 6 standard. These technologies reduce contention and improve efficiency, allowing the AP to serve more clients simultaneously without the degradation in performance typically seen with older Wi-Fi standards. It is a robust solution for busy offices.
