Mfr.part#:	WS-C3850-16XS-S Rating: 95% 4.8/5.0 4 Reviews
Name:	WS-C3850-16XS-S Catalyst 3850 Switch
Detail:	Catalyst 3850 16-port SFP+ transceiver, 1 network module slot, support for up to 10 G SFP+, 350 W power supply. WS-C3850-16XS-S
Availability:	In Stock
Condition:	New
Price:	$6,524.40

WS-C3850-16XS-S

Quantity:

Request Bulk Quote

Shipping:

Free ground shipping within United States up to 10LBS

᛫ Items in stock will arrive within the estimated delivery time.
᛫ Preordered items need to be negotiated for delivery time.
᛫ Compensation if delivery delayed.

Accepting POs:

We accept Purchase Orders from Government Agencies, Defense, Hospitals, Universities, Schools and Businesses.

Payment:

Pay by Visa.
Pay with your Visa credit card.
Pay with your Discover Card.
Pay with your America Express.
Pay with your JCB.
Pay with your Wire Transfer.

Genuine Guarantee
Price Protection
Bulk Order Rebate
30 Day Return Policy

Laila Jones

Technical Customer Support

CHAT
EMAIL
WHATSAPP

(800) 870-9487

overview

specifications

reviews

overview

Overview

WS-C3850-16XS-S Overview

Cisco WS-C3850-16XS-S supports 12 SFP+ port stackable model, with C3850-NM-4-10G module and 350WAC power supply. 1 RU, and IP Base feature set. Cisco Catalyst 3850 Series provides capabilities that ideally suited to support the convergence of wired and wireless access. The new Cisco Unified Access Data™ Plane (UADP) Application-Specific Integrated Circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility, and application optimization. This convergence is built on the resilience of the new and improved Cisco StackWise®-480 technology.

Quick Specs

Table 1 shows the Quick Specs.

Product Code	WS-C3850-16XS-S
Enclosure Type	1 RU
Feature Set	IP Base
Ports	12 SFP+ ports and 4 10G SFP ports (C3850-NM-4-10G)
Network Module	Shipped with C3850-NM-4-10G module
RAM	4GB
Flash Memory	4GB
Switching capacity	320 Gbps
Dimension	Width: 17.5 in Depth: 17.7 in Height: 1.8 in

The Accessories

Table 2 shows some recommended accessories of this switch.

Models	Description
L-LIC-CTIOS-1A	1 AP Adder License for the IOS based Wireless Controller (e-delivery)
STACK-T1-50CM=	Cisco StackWise-480 50cm stacking cable for Cisco Catalyst 3850 series switch
PWR-C1-350WAC/2	Cisco 3850 Series Secondary Power Supply PWR-C1-350WAC/2 350W AC Config 1 Secondary Power Supply
PWR-C1-715WAC/2	Cisco 3850 Series Secondary Power Supply PWR-C1-715WAC/2 715W AC Config 1 Secondary Power Supply
PWR-C1-1100WAC/2=	Cisco 3850 Series Secondary Power Supply PWR-C1-1100WAC/2 1100W AC Config 1 Secondary Power Supply

Compare to Similar Item

Table 3 shows the comparison.

Product Code	WS-C3850-16XS-S	WS-C3850-12XS-S
Enclosure Type	1 RU	1 RU
Feature Set	IP Base	IP Base
Ports	12 SFP+ ports and 4 10G SFP ports (C3850-NM-4-10G)	12 x 10/100/1000 10G SFP+ Optical ports
Network Module	Shipped with C3850-NM-4-10G module	C3850-NM-4-10G (Needed to buy separately)
RAM	4GB	4GB
Flash Memory	4GB	4GB
Switching capacity	320 Gbps	320 Gbps

Comparison Download

[PDF] Comparison: Cisco Switches vs. HPE/Aruba Switches

Get more information

Do you have any question about the WS-C3850-16XS-S?

100% Low Price Guarantee

We offer high-quality network parts at wholesale prices that are guaranteed to be low.

What is the minimum price for the Cisco WS-C3850-16XS-S?

Our lowest price for WS-C3850-16XS-S is $6,524.40 Buy Now

Explore even more affordable prices for Switches and Cisco products.

specifications

Specification

WS-C3850-16XS-S Specification

WS-C3850-16XS-S Specification
Capacity	64 Wireless LANs
Dimensions & Weight	Width: 17.5 in Depth: 17.7 in Height: 1.8 in Weight: 12.79 lbs
Environmental Parameters	Min Operating Temperature: 23 °F Max Operating Temperature: 113 °F Humidity Range Operating: 10 - 95% (non-condensing) Min Storage Temperature: -40 °F Max Storage Temperature: 158 °F
Switching capacity	320 Gbps
RAM	4GB
Flash Memory	4GB
Interface Provided	Qty: 4 Type: Management (mini-USB) Connector Type: Type B Comments: Management
Miscellaneous	Compliant Standards: AS/NZS 3548 Class A, AS/NZS CISPR 22, BSMI Class A, CAN/CSA C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CNS 13438, EN 300386, EN 55022 Class A, EN 60950-1, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-1, EN50082-1, EN55024, FCC CFR47 Part 15, FCC Part 15 A, ICES-003 Class A, IEC 60950-1, IEC 60950-1 Second Edition, KCC, KN22 Class A, KN24, NOM, RoHS 5/6, UL 60950-1, UL 60950-1 Second Edition, VCCI Class A Authentication Method: Kerberos, RADIUS, Secure Shell (SSH), TACACS+ MTBF: 371,440 hours Height (Rack Units): 1U
Software	Cisco IOS IP Base
Power Device	Frequency Required: 50 - 60 Hz Power Provided: 350 Watt Installed Qty: 1 Max Supported Qty: 2 Nominal Voltage: AC 120/230 V Power Redundancy: Optional Power Redundancy Scheme: 1+1 (with optional power supply) Type: Internal power supply
