WS-C3850-16XS-E Overview
Catalyst 3850 16-port SFP+ transceiver, 1 network module slot, support for up to 10 G SFP+, 350 W power supply WS-C3850-16XS-E
Overview
WS-C3850-16XS-E Overview
Cisco Catalyst WS-C3850-16XS-E, Managed, Rack mounting
Cisco WS-C3850-16XS-E supports 12 SFP+ port stackable model, with C3850-NM-4-10G module and 350WAC power supply. 1 RU, and IP Servuces feature set. Cisco Catalyst 3850 Series provides capabilities that ideally suited to support the convergence of wired and wireless access. The new Cisco Unified Access Data™ Plane (UADP) Application-Specific Integrated Circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility, and application optimization. This convergence is built on the resilience of the new and improved Cisco StackWise®-480 technology.
Quick Spec
Product Code | WS-C3850-16XS-E |
Enclosure Type | 1 RU |
Feature Set | IP Services |
Ports | 12 SFP+ ports and 4 10G SFP ports (C3850-NM-4-10G) |
Network Module | Shipped with C3850-NM-4-10G module |
RAM | 4GB |
Flash Memory | 4GB |
Switching capacity | 320 Gbps |
Dimension | Width: 17.5 in Depth: 17.7 in Height: 1.8 in |
The Accessories
Models | Description |
L-LIC-CTIOS-1A | 1 AP Adder License for the IOS based Wireless Controller (e-delivery) |
Cisco StackWise-480 50cm stacking cable for Cisco Catalyst 3850 series switch | |
Cisco 3850 Series Secondary Power Supply PWR-C1-350WAC/2 350W AC Config 1 Secondary Power Supply | |
Cisco 3850 Series Secondary Power Supply PWR-C1-715WAC/2 715W AC Config 1 Secondary Power Supply | |
Cisco 3850 Series Secondary Power Supply PWR-C1-1100WAC/2 1100W AC Config 1 Secondary Power Supply |
Compare to Similar Item
Product Code | WS-C3850-16XS-E | |
Enclosure Type | 1 RU | 1 RU |
Feature Set | IP Services | IP Base |
Ports | 12 SFP+ ports and 4 10G SFP ports (C3850-NM-4-10G) | 12 x 10/100/1000 10G SFP+ Optical ports |
Network Module | Shipped with C3850-NM-4-10G module | C3850-NM-4-10G (Needed to buy separately) |
RAM | 4GB | 4GB |
Flash Memory | 4GB | 4GB |
Switching capacity | 320 Gbps | 320 Gbps |
Switch to Something New
Why Upgrade to Catalyst 9300? | See the Catalyst 9300 Series
Catalyst 3850, Stackable, 12 Port, SFP+, 350W, 1 RU, IP Services feature set
- Managed SNMP v1, SNMP v2c, SNMP v3
- Quality of Service (QoS) support
- MAC address table: 32000 entries
- Access Control List (ACL)
- Rack mounting Stackable
Summary Description
Cisco Catalyst WS-C3850-16XS-E, Managed, Rack mounting
Need help with WS-C3850-16XS-E?
Get pricing, availability, lead time, and compatible options from our team. Chat with us live or email support@buyrouterswitch.com
Specification
WS-C3850-16XS-E Specification
WS-C3850-16XS-E Specification | |
Capacity | 64 Wireless LANs |
Dimensions & Weight | Width: 17.5 in Depth: 17.7 in Height: 1.8 in Weight: 12.79 lbs |
Environmental Parameters | Min Operating Temperature: 23 °F Max Operating Temperature: 113 °F Humidity Range Operating: 10 - 95% (non-condensing) Min Storage Temperature: -40 °F Max Storage Temperature: 158 °F |
Switching capacity | 320 Gbps |
RAM | 4GB |
Flash Memory | 4GB |
Interface Provided | Qty: 4 Type: Management (mini-USB) Connector Type: Type B Comments: Management |
Miscellaneous | Compliant Standards: AS/NZS 3548 Class A, AS/NZS CISPR 22, BSMI Class A, CAN/CSA C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CNS 13438, EN 300386, EN 55022 Class A, EN 60950-1, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-1, EN50082-1, EN55024, FCC CFR47 Part 15, FCC Part 15 A, ICES-003 Class A, IEC 60950-1, IEC 60950-1 Second Edition, KCC, KN22 Class A, KN24, NOM, RoHS 5/6, UL 60950-1, UL 60950-1 Second Edition, VCCI Class A
Authentication Method: Kerberos, RADIUS, Secure Shell (SSH), TACACS+
MTBF: 371,440 hours Height (Rack Units): 1U |
Software | Cisco IOS IP Services |
Power Device | Frequency Required: 50 - 60 Hz Power Provided: 350 Watt Installed Qty: 1 Max Supported Qty: 2 Nominal Voltage: AC 120/230 V Power Redundancy: Optional Power Redundancy Scheme: 1+1 (with optional power supply) Type: Internal power supply |
Frequently Asked Questions
What are the primary interface capabilities of the Cisco WS-C3850-16XS-E? +
This model features 16 fixed 10 Gigabit Ethernet SFP+ ports, designed for high-density, high-speed fiber connectivity in the aggregation layer. Additionally, it includes a single dedicated network module slot, allowing for further uplink flexibility to suit your specific data center or campus topology requirements.
Does the WS-C3850-16XS-E support software-defined networking features? +
Yes, this unit comes pre-installed with the IP Services (E) feature set. This advanced licensing tier provides robust Layer 3 routing capabilities, including OSPF, EIGRP, BGP, and IS-IS, making it an ideal candidate for integration into sophisticated software-defined access architectures and enterprise-grade routed environments.
Can I stack the Cisco Catalyst 3850-16XS units to increase port density? +
Absolutely. The Catalyst 3850 series utilizes Cisco StackWise-480 technology, which provides a high-speed stacking bandwidth of 480 Gbps. By interconnecting multiple units, you can manage them as a single logical entity, effectively scaling your throughput and simplifying administrative tasks across your switching infrastructure.
What is the power capacity of the included 350W power supply? +
The WS-C3850-16XS-E ships with a 350W AC power supply, which is sufficient to handle the standard operational power requirements of the switch chassis and its active SFP+ interfaces. In mission-critical environments, you can add a secondary modular power supply for power redundancy.
Which types of transceivers are compatible with the SFP+ ports on this switch? +
The 16 SFP+ ports support a wide range of Cisco-certified 10GBASE-SR, 10GBASE-LR, and 10GBASE-ER optical transceivers. It is also compatible with SFP+ Direct Attach Copper (DAC) cables for short-reach, low-latency connections within a single rack or adjacent server cabinets.
What are the primary management protocols supported by the Catalyst 3850? +
You can manage this switch via the industry-standard Command Line Interface (CLI), Cisco Prime Infrastructure, or the integrated web-based GUI. It supports SNMPv3, SSHv2, and NETCONF for programmatic control, allowing for seamless integration into modern IT management platforms and automated orchestration workflows.
How does the WS-C3850-16XS-E handle hardware-based encryption? +
The switch is equipped with Cisco StackWise-480 and integrated hardware support for MACsec (IEEE 802.1AE). This allows for line-rate hardware encryption on all ports, ensuring that your data-in-transit is protected from interception at the link layer without compromising switching performance or port latency.
Is this switch suitable for high-performance aggregation in a campus network? +
Given its 16-port 10G density and advanced IP Services routing capabilities, the WS-C3850-16XS-E is perfectly positioned as a high-performance aggregation switch. It provides the necessary throughput to aggregate traffic from multiple access-layer switches while maintaining the intelligent routing policies required for modern multi-service campus networks.
