Name: PVDM3-16 Router Voice DSP Module
Brand: Cisco
SKU: PVDM3-16
Price: 50.75 USD
Availability: InStock

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Name:	PVDM3-16 Router Voice DSP Module
Mfr. Part #	PVDM3-16
Condition:	Refurbished
Availability:	In Stock
Brand:	Cisco
Price:	$50.74

PVDM3-16

Quantity:

Request Bulk Quote

Shipping:

Free ground shipping within United States up to 10LBS

᛫ Items in stock will arrive within the estimated delivery time.
᛫ Preordered items need to be negotiated for delivery time.
᛫ Compensation if delivery delayed.

Accepting POs:

We accept Purchase Orders from Government Agencies, Defense, Hospitals, Universities, Schools and Businesses.

Genuine Guarantee
Price Protection
Bulk Order Rebate
30 Day Return Policy

overview

specifications

resources

reviews

overview

PVDM3-16 Overview

16-channel high-density voice and video DSP module PVDM3-16

Overview

Cisco PVDM3-16=, -5 - 55 °C, 10 - 85%

The PVDM3 brings new rich-media capabilities to Cisco® Unified Communications Solutions. High-density voice connectivity. Conferencing, transcoding, and transrating. Management of voice quality. Power savings, secure voice, and more. The module resides on the Cisco 2900 and 3900 Series routers to enable these capabilities.

The next-generation high-density packet voice digital-signal-processor (DSP) modules are available in six densities: PVDM3-16, PVDM3-32, PVDM3-64, PVDM3-128, PVDM3-192, and PVDM3-256. The modules have 16, 32, 64, 128, 192, and 256 channels, respectively.

Quick Specs

Product Code	PVDM3-16
Description	16-channel high-density voice DSP module
Maximum Number of Channels in Low-Complexity Codecs	16
Maximum Number of Channels in Medium-Complexity Codecs	12
Maximum Number of Channels in High-Complexity Codecs	10
Platform Support	Cisco 2901, 2911, 2921, 2951, 3925, 3945, 3925-E, and 3945-E Integrated Service Routers
Availability	Unified Communications License on Universal Cisco IOS Software image
Release	Cisco IOS Software Release 15.0(1)M

Compare to Similar Items

Product Code	PVDM3-16	PVDM3-32	PVDM3-64	PVDM3-128	PVDM3-192	PVDM3-256
Description	16-channel high-density voice DSP module	32-channel high-density voice DSP module	64-channel high-density voice DSP module	128-channel high-density voice DSP module	192-channel high-density voice DSP module	256-channel high-density voice DSP module
Maximum Number of Channels in Low-Complexity Codecs	16	32	64	128	192	256
Maximum Number of Channels in Medium-Complexity Codecs	12	21	42	96	138	192
Maximum Number of Channels in High-Complexity Codecs	10	14	28	60	88	120

Summary Description

Cisco PVDM3-16, -5 - 55 °C, 10 - 85%

Need help with PVDM3-16?

Get pricing, availability, lead time, and compatible options from our team. Chat with us live or email support@buyrouterswitch.com

specifications

Specification

PVDM3-16 Specification

PVDM3 Modules Specifications
Components
DSP	Multicore DSP technology
DSP external memory	512-megabit double-data-rate (DDR) synchronous dynamic random access memory (SDRAM) for each DSP
Interface	240-pin dual-inline-memory-module (DIMM) interface
Features
Echo cancellation	Software echo cancellation compliant with ITU-T G.168, with 128-ms tail coverage
Operating temperature	-41 to 131°F (-5 to 55°C)
Voltage	3.3V
Current	1.47A
Power	4.85W
Regulatory and Compliance
Safety	● Complies with IEC 60950 (worldwide) and AS/NZS 60950-1 (Australia and New Zealand), CAN/CSA-C22.2 No. 60950-1, 1st and 2nd Ed. (Canada), and GB4943-95 (People's Republic of China) ● EN60950-1, 1st and 2nd Ed. (CENELEC; includes EU and EFTA) ● NOM-019-SCFI-1998 (Mexico), and UL 60950-1, 1st and 2nd Ed. (United States)
Homologation	Platform dependent
Mean time between failure (MTBF)	System dependent
EMC
Emissions	● CISPR22, Class B ● EN55022, Class B, CFR47, Part 15, Subpart B, Class B
Harmonics	EN61000-3-2
Flicker	EN61000-3-3
Immunity	● CISPR24 ● EN 55024 ● EN50082-1
Electrostatic discharge (ESD)	EN 61000-4-2
RF fields	EN 61000-4-3
EFT	EN 61000-4-4
Surge	EN 61000-4-5
Conducted RF	EN 61000-4-6
Power-frequency magnetic fields	EN 6100-4-8
Voltage dips, sags, and interruptions	EN 61000-4-11
