| Name: |
INTERLINE PL Horizon, 12 dBi, 5.75 - 6.15 GHz, IEEE 802.1p, 12 dBi, 50 Ω, 360° |
| Mfr. Part #: |
IH-G12-F5761-V
|
| Condition: | Refurbished |
| Availability: | In Stock |
| Brand: | INTERLINE PL |
INTERLINE PL Horizon network antenna Omni-directional antenna N-type 12 dBi
Shipping:
Free ground shipping within United States up to 10LBS
Accepting POs:
We accept Purchase Orders from Government Agencies, Defense, Hospitals, Universities, Schools and Businesses.
-
Genuine Guarantee
-
Price Protection
-
Bulk Order Rebate
-
30 Day Return Policy
overview
specifications
reviews
IH-G12-F5761-V Overview
HORIZON series antennas are one of the most famous omnidirectional antennas available on the market. Carefully constructed, small, perfectly suited for the base stations of medium-range using a single access point. In locations where there is a large number of other networks, particular attention should be on the selection of the proper range for the cells and antennas should not have too big gain, because the access points connected to them are likely to receive unwanted signals coming to them from distant networks.
IEEE 802.11p / DSRC / WAVE
The antenna also operates in the DSRC frequencies used in the IEEE 802.11p WAVE. The antenna can be used in ITS (Intelligent Transportation Systems) to increase the road coverage of base stations RSU. By increasing the range, you can reduce the number of stations needed to handle traffic of a road section.
IEEE 802.11p, DSRC, WAVE, PTFE, 5750-6150MHz, 12dBi, VSWR 1.50:1, 50Ω
- Omni-directional antenna N-type Black, White
- 12 dBi
- 5.75 - 6.15 GHz
- 50 Ω
- Vertical polarization
- Wall/Pole
Summary Description
INTERLINE PL Horizon, 12 dBi, 5.75 - 6.15 GHz, IEEE 802.1p, 12 dBi, 50 Ω, 360°
Need help with IH-G12-F5761-V?
Get pricing, availability, lead time, and compatible options from our team. Chat with us live or email support@buyrouterswitch.com
IH-G12-F5761-V Specifications
Overview
Manufacturer:
INTERLINE PL
Stock:
In Stock.
Stock updated on:
2024-08-27
Performance
Frequency band
5.75 - 6.15 GHz
Networking standards
IEEE 802.1p
Antenna gain (5 GHz)
12 dBi
Impedance
50 Ω
Horizontal beam width
360°
Vertical beam width
6°
Antenna gain level (max)
12 dBi
Features
Antenna type
Omni-directional antenna
Antenna connector type
N-type
Polarization
Vertical polarization
Voltage Standing Wave Ratio (VSWR)
1.50:1
International Protection (IP) code
IP64
Waterproof
Yes
Ultraviolet (UV) resistant
Yes
Mounting
Wall/Pole
Purpose
Outdoor
Type of clamp
U-bolt
Mounting pipe
38 - 51 mm
Product colour
Black, White
Certification
2002/96/EC (WEEE)
Technical details
Compliance certificates
RoHS
Weight & dimensions
Height
465 mm
Diameter
2.6 cm
Weight
320 g
