Mfr.part#:	GLC-BX40-DA-I
Name:	GLC-BX40-DA-I - Cisco SFP GLC Module
Detail:	1000BASE-BX10 SFP module for single-strand SMF, 1490-nm TX/1310-nm RX wavelength, single LC/PC connector GLC-BX40-DA-I
Availability:	In Stock
Condition:	Original
Price:	$776.10

GLC-BX40-DA-I

Quantity:

Request Bulk Quote

Shipping:

Free ground shipping within United States up to 10LBS

᛫ Items in stock will arrive within the estimated delivery time.
᛫ Preordered items need to be negotiated for delivery time.
᛫ Compensation if delivery delayed.

Accepting POs:

We accept Purchase Orders from Government Agencies, Defense, Hospitals, Universities, Schools and Businesses.

Payment:

Pay by Visa.
Pay with your Visa credit card.
Pay with your Discover Card.
Pay with your America Express.
Pay with your JCB.
Pay with your Wire Transfer.

Genuine Guarantee
Price Protection
Bulk Order Rebate
30 Day Return Policy

Laila Jones

Technical Customer Support

CHAT
EMAIL
WHATSAPP

(800) 870-9487

overview

specifications

resources

reviews

overview

Overview

GLC-BX40-DA-I Overview

Cisco GLC-BX40-DA-I. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Product colour: Grey. Power consumption (typical): 1 W. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm. Number of products included: 1 pc(s)

Cisco GLC-BX40-D-I is a 1000BASE-BX10 SFP module for single-strand SMF, delivering 1490-nm TX/1310-nm RX wavelength and single LC/PC connector.

Quick Spec

Table 1 shows the quick spec.

Part Number	GLC-BX40-DA-I
Type	SFP (mini-GBIC) transceiver module
Wavelength (nm)	1490 (TX) / 1310 (RX) nm
Fiber Type	Ethernet 1000Base-BX
Connector Type	LC single-mode
Max Transfer Distance	40KM

Product Details

1000BASE-BX40-D and 1000BASE-BX40-U for Single-Fiber Bidirectional Applications

The Cisco GLC-BX40-D-I, GLC-BX40-DA-I and GLC-BX40-U-I SFPs operate on a single strand of standard SMF.

A GLC-BX40-D-I or GLC-BX40-DA-I device connects to a GLC-BX40-U-I device with a single strand of standard SMF with an operating transmission range up to 40 km. The communication over a single strand of fiber is achieved by separating the transmission wavelength of the two devices.

The GLC-BX40-D-I, GLC-BX40-DA-I, and GLC-BX40-U-I SFPs also support digital optical monitoring (DOM) functions according to the industry-standard SFF-8472 multisource agreement (MSA). This feature gives the end user the ability to monitor real-time parameters of the SFP, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.

Compare to Similar Item

Table 2 shows the comparison.

Part Number	GLC-BX40-D-I	GLC-BX40-DA-I
Type	SFP (mini-GBIC) transceiver module	SFP (mini-GBIC) transceiver module
Wavelength (nm)	1550 (TX) / 1310 (RX) nm	1490 (TX) / 1310 (RX) nm
Fiber Type	1000Base-BX40-D	Ethernet 1000Base-BX
Mode	LC/PC single-mode	LC single-mode
Max Transfer Distance	40KM	40KM

Get more information

Do you have any question about the GLC-BX40-DA-I?

1000BASE-BX40-D (Alternative) for 40km Single-Fiber Bidirectional Applications, with DOM, 1490 nm

Hot swappable to maximize uptime and simplify serviceability

Flexibility of media and interface choice on a port-by-port basis, so you can “pay as you populate”

Robust design for enhanced reliability

Supports Digital Optical Monitoring (DOM) capability

SFP Fiber optic 1000 Mbit/s

Wavelength: 1490 nm

Hot-swap

Power consumption (typical): 1 W

Summary Description

Cisco GLC-BX40-DA-I, Fiber optic, 1000 Mbit/s, SFP, 40000 m, 1490 nm, 1480 nm

100% Low Price Guarantee

We offer high-quality network parts at wholesale prices that are guaranteed to be low.

What is the minimum price for the Cisco GLC-BX40-DA-I?

Our lowest price for GLC-BX40-DA-I is $776.10 Buy Now

Explore even more affordable prices for Networking Accessories and Cisco products.

specifications

Specification

GLC-BX40-DA-I Specification

GLC-BX40-DA-I Specification
Device Type	SFP (mini-GBIC) transceiver module
Form Factor	Plug-in module
Connectivity Technology	Wired
Cabling Type	Ethernet 1000Base-BX
Data Link Protocol	Gigabit Ethernet
Optical Wave Length	1490 (TX) / 1310 (RX) nm
Max Transfer Distance	40KM
