Complete Guide to the RTX 4080 Super : Specifications, Performance, and Setup
Table of content
Introduction:
If you are a gaming enthusiast or a part of a company that does creative projects, the NVIDIA RTX 4080 Super can be a good choice for you. It provides you with more than 4-5% improvement in overall performance as compared to its slightly minor version. Generally speaking, it is a minor upgrade to the original RTX 4080 but offers much more than one can expect. From price, performance, frequency boost, and 22.4 Gbps to 23 Gbps VRAM speed, RTX 4080 Super provides these features while maintaining the same power consumption at 320W. In this blog, we’ll explore 4080 super specifications, performance, and comparison with the original version.
What is RTX 4080 Super:
The GeForce 4080 Super is a high-end graphics card that efficiently handles high-resolution games and creative projects. It combines the capabilities of its original version and the RTX 4090 by offering unparalleled features. It is based on the AD103 graphics processor (specifically the AD103-400-A1 variant) and uses a 5 nm manufacturing process. In addition, it can run all modern games and offers up to 84 fps at 4K, supporting DirectX 12 Ultimate.
Specifications of RTX 4080:
| Specifications | Details |
| Graphics processing clusters | 7 |
| Texture processing clusters | 40 |
| Streaming multiprocessors | 80 |
| CUDA cores | 10,240 |
| Tensor cores | 320 (4th generation) |
| RT cores | 80 (3rd generation) |
| Texture units | 320 |
| ROP units | 112 |
| Base clock | 2,295 MHz |
| Boost clock | 2,550 MHz |
| Memory clock | 11,500 MHz |
| Memory data rate | 23 Gbps |
| L1 data cache/shared memory | 10,240 K |
| L2 cache size | 65,536 K |
| Total video memory | 16GB GDDR6X |
| Memory interface | 256-bit |
| Connectors | 3x DisplayPort, 1x HDM |
| Form factor | Triple slot |
| Power connectors | 3x PCIe 8-pin cables (adapter in box) OR 450W or greater PCIe Gen 5 cable |
| Required system power supply | 750 Watts |
| Video engines | 2xNVENC (8th Gen) with AV1, 1xNVDEC (5th Gen) |
| Power | 15W Idle, 22W AV1 Video Playback, 246W Average Gaming Power (AGP), 320W Total Graphics Power (TGP) |
| Max GPU temperature | 90° C |
NVIDIA GeForce RTX 4080 Super Specifications Compared:
| Specs |
Nvidia GeForce RTX 4080 Supe |
Nvidia GeForce RTX 4080 |
| Architecture | Ada Lovelace | Ada Lovelace |
| Date of Introduction | January 2024 | November 2022 |
| Manufacturing Process & Die Size | TSMC 4N 4nm / 379mm2 | TSMC 4N 4nm / 379mm2 |
| Transistor Count | 45.9 billion | 45.9 billion |
| Processing Cores | 10,240 CUDA cores | 9,728 CUDA cores |
| Texture Mapping Units (TMUs) | 320 | 304 |
| Raster Operation Processors (ROPs) | 112 | 112 |
| Ray Tracing Cores | 80 | 76 |
| GPU Base Clock | 2,295MHz | 2,210MHz |
| GPU Boost Clock | 2,550MHz | 2,505MHz |
| Video Memory | 16GB GDDR6X | 16GB GDDR6X |
| Memory Interface / Bandwidth | 256-bit / 736GBps | 256-bit / 717GBps |
| Board Power | 320 watts | 320 watts |
Nvidia GeForce RTX 4080 Super – Performance:
When it comes to its performance, RTX 4080 Super has more CUDA cores that help it improve parallel processing capabilities. Besides, its higher base and boost clock speeds enhance overall performance is a significant improvement as compared to original RTX 4080. In addition, it has more memory bandwidth and capacity that enables quick data transfer resulting in complex computations and high-resolution gaming. Last but not least is the power efficiency that give a significant boost to performance without increasing power consumption.
05 Important Points Regarding RTX 4080 Super:
Performance at 4K Resolution:
The RTX 4080 Super excels in 4K gaming, particularly with Nvidia’s DLSS technology. For example, in “Cyberpunk 2077,” it achieves 84 fps at 4K with DLSS on performance mode, increasing to 111 fps with Frame Generation.
Comparison to RTX 4080:
The performance improvement over the original RTX 4080 is marginal, about 5% in some cases, but it comes at a lower price point. The RTX 4080 performs similarly to the RTX 4080 in various benchmarks.
Comparison to AMD Radeon RX 7900 XTX:
In games like “Total War: Warhammer 3,” the RTX 4080 Super performs well, though it is slightly behind the AMD Radeon RX 7900 XTX.
Synthetic Benchmarks:
The RTX 4080 Super shows a 4% improvement in the Port Royal benchmark and performs well in the Speed Way benchmark compared to both the RTX 4080 and the Radeon RX 7900 XTX.
Comparison to RTX 4090:
The RTX 4080 is significantly cheaper than the RTX 4090, which is about 20-25% faster but also 60% more expensive. This price-performance ratio makes the RTX 4080 Super a better value for money compared to the RTX 4090.
The Most Important Part:
It is definitely a super improvement to its predecessors. But, the most important thing is its price is still higher but reasonable as compared to GeForce RTX 4080 and others.
Imagine going for the best gaming performance with high-level resolution and quality without feeling tense about budget. Who wants to pay the full price when there is an alternative that is significantly lower in price and better in performance?
Conclusion:
NVIDIA RTX 4080 Super is the best-ever choice for gaming scenarios as professional creative projects. Compared to its original version, the 4080 Super provides better overall performance and, most importantly, a slight difference in price. For anyone who wants a productive shift from 4080 original to a better option at fair rates, RTX 4080 super is the nearest and best choice. In the end, if you are looking for the best routers, switches, or insights on other networking accessories, hit us up at Buyrouterswitch.com. We have all you are striving for.
Frequently Asked Questions:
Is the RTX 4080 Super worth it?
The RTX 4080 Super is considered the best GPU in the present gaming market other than RTX 4090. Alongside enhanced bandwidth, energy efficiency, and overall performance, its lower price makes it a perfect choice in the consumer market.
What’s better, a 4080 or a 4080 super?
The RTX 4080 Super is better than its previous version, as the name shows itself. The main difference is in their performance, which is 4-5% better in RTX 4080 Super. Besides, the Nvidia 4080 Super has 5% more CUDA Cores than its predecessor.
Is 4080 super enough for 4K gaming?
Providing a comparatively lower pricing option and better performance than its predecessor, the NVIDIA RTX 4080 Super is the best choice for 4K gaming scenarios. The best part is its price equals a mid-range gaming PC while it provides a killer performance.
