The HPE JL383A Aruba switch comes under the HPE Office Connect 1920S Aruba Switch Series, which is a variety of modern smart-engineered Gigabit switches with fixed configuration. Particularly, these switches are manufactured to provide easy-to-manage networking solutions to small-size businesses. The JL383A switch offers a total of 8 ports that function at Gigabit (10/100/1000 Mbps) speed. Besides the 8 configuration ports, the switch has four other ports that support PoE+, which allow you to power compatible devices such as IP cameras, VoIP phones, and wireless access points directly through the Ethernet cable, eliminating the need for separate power sources. The Switch possesses smart management setups, which means it provides extraordinary management that makes it a perfect fit for small businesses needing advanced features without facing any complexities. In general, the JL383A Aruba switch is Gigabit as well as economical and meets every requirement of small businesses.

In this blog, we will delve into the features and specifications of the JL383A Aruba switch to cover the most important things you should know about the HPE Office Connect 1920 Aruba Switch Series.

Key Specifications of JL383A Aruba Switch:

8 Ports – L3 – Managed:

This switch is a managed Layer 3 switch with 8 ports, which means it can perform routing functions and is capable of being controlled and configured for specific network requirements.

Desktop, Rack-mountable, Wall-mountable 1U:

The Aruba JL383A switch can be installed in various ways, including on a desktop, mounted in a rack, or on a wall. Its 1U form factor makes it suitable for standard rack-mount installations.

Gigabit Ethernet:

It is a Gigabit Ethernet switch, meaning it supports data transfer rates of up to 1 gigabit per second per port.

Ports: 4 x 10/100/1000 (PoE+) + 4 x 10/100/1000

The switch has a total of 8 ports, with 4 of them supporting Power over Ethernet (PoE+), which can provide power to connected devices such as IP phones or cameras.

Power Over Ethernet (PoE): PoE+

This switch supports the PoE+ standard, which allows for higher power delivery to connected PoE devices.

PoE Budget: 65W

The switch can provide a total PoE power budget of 65 watts to its PoE-enabled ports

Performance:

Latency (1 Gbps), Routing/Switching Capacity (16 gigabits per second), throughput: Up to 11.9 million packets per second, Mac Address Table Size (8000 entries), and other performance specifications make JL383A switch a prime option for you networking infrastructure.

IGMP, Static IPv4 Routing:

The switch provides IGMP for managing multicast traffic and static IPv4 routing for routing traffic between different subnets.

Remote Management Protocol: SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS

The switch can be managed remotely using various protocols, including SNMP (Simple Network Management Protocol) and HTTP/HTTPS for web-based management.

Authentication Method: RADIUS:

It supports RADIUS (Remote Authentication Dial-In User Service) for secure authentication of users accessing the network.

Main Features Of The JL383A Aruba Switch:

The switch offers a variety of features including flow control, auto-negotiation, IGMP snooping, IPv6 support, spanning tree protocols, access control lists (ACLs), Quality of Service (QoS), fanless design, DHCP relay, DHCP client, port isolation, class of service (CoS), and more.

• It adheres to various IEEE standards such as IEEE 802.1d, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, and IEEE 802.1s, ensuring compatibility and interoperability with other networking equipment.
• The switch is powered by a 400 MHz ARM Cortex-A9 processor for handling its management and routing functions.
• It has 256 megabytes of SDRAM (System Dynamic Random-Access Memory) for temporary data storage and processing.
• The switch has 64 megabytes of flash memory for storing its operating system and configuration files.
• The switch includes 4 x 1000Base-T RJ-45 PoE+ ports and 4 x 1000Base-T RJ-45 ports for connecting devices.
• The switch requires AC power input at either 120 or 230 volts with a frequency of 50/60 Hz for operation.

Conclusion:

From a detailed overview of the JL383A switch to its key specifications and features, we hope to have explored a vast area of Aruba Office Connect Switches. We brought you study and research-driven information about the HPE JL383A switch. Now, if you have any questions that need to be answered, Buyrouterswitch.com is always open for you. If you want any information and updates on Aruba switches, whether Aruba Switch v2 Modules or Aruba Data Center Switches, we are always ready to guide you along the way.
